TRIM AND TILT
SERVICE CHART
327
13
25” MODELS (THREE PISTON SYSTEM)
DSS130
A Triple-Guard Grease
B Gasket Sealing Compound
C Adhesive 847
D Moly Lube
E Red Ultra Lock
F Blue Nut Lock
G Needle Bearing Grease
60-70 Ft. lbs.
(81-95 N·m)
DO NOT OVER TIGHTEN
84-108 In. lbs.
(9.5-12 N·m)
58-87 Ft. lbs.
(79-118 N·m)
35-52 In. lbs.
(4.0-5.9 N·m)
60-84 In. lbs.
(7-9.5 N·m)
45-55 In. lbs.
(5.1-6.2 N·m)
35-52 In. lbs.
(4.0-5.9 N·m)
60-84 In. lbs.
(7-9.5 N·m)
12-24 In. lbs.
(1.4-2.7 N·m)
A
58-87 Ft. lbs.
(79-118 N·m)
FF
