ADJUSTMENTS
tbl2013-009-022_b
FRONT S USPENSION — X RS M ODELS
1. Preload adj
ustment
2. Low speed and high speed compression damping adjuster
3. Rebound adjuster
tbl2013-009-026_b
REAR SUSPENSION — BASE M ODELS
1. Preload adjustment
2. Co mpression damping clicker
tbl2013-009-027_b
REAR SUSPEN
SION — X RS MODELS
1. Preload adjustment
2. Low spee d and high speed compression damping adjuster
3. Rebound adj
uster
Suspension Factory Settings
For adjustment procedures, refer to SPRING
PRELOAD ADJUSTMENT (FRONT AND REAR)
and SHOCK DAMPING ADJUSTMENTS (FRONT
AND REAR)
in this section.
To adjust c
ompression and rebound to factory set-
tings, pro
ceed as follows:
1. Turn adjuster clockwise until it stops.
2. Turn adjuster counterclockwise by the specified
amount, see table below.
FRONT SUSPENSION FACTORY SETTINGS
ADJUST
MENT
MODEL FACTOR
Y SETTING
Base 78.3 mm (3.08 in)
Spring preload
XrsDPS
103 mm
(4.05 in)
Compression damping
Base 12 positions
Compression damping
(low speed)
XrsDPS
9 posi
tions
Compression damping
(high speed)
XrsDPS
9 posi
tions
Rebound damping
XrsDPS
12 positions
