FLUIDS
tmo2011-001-075_a
UNDER PASSENGER'S SEAT
1. Dipstick
2. Reinstall dipstick, screw in it completely.
3. Remove and c
heck oil level. It should be near
or equal to
the upper mark.
tmo2011-001-076_a
TYPICAL
1. MIN
2. MAX
3. Operating range
To add oil, remove the dipstick. Place a funnel into
the dipstick tube.
Add a small amount of rec
ommended oil and
recheck oil level.
Repeat the above procedures until oil level
reaches the dipstick upper mark.
NOTE: Do not overfill. Wipe off any spillage.
Properly tighten dips
tick.
Engine Coolant
Recommended Engine Coolant
COOLANT HEADER
BRP recommended
product
LONG LIFE ANTIFREEZE
(P/N 219 702 685)
Alternative if not
available
Distilled water and
antifreeze solution (50%
distilled water, 5 0 %
antifreeze)
NOTICE
Always use ethylene-glycol an-
tifreeze containing corrosion inhibitors specif-
ically for internal combustion aluminum en-
gines.
Engine Coolant Level Verification
WARNING
Check coolant
level with engine cold.
Place vehicle on a level surface.
Unlatch service cover as follows.
NOTICE
Failure to follow the described proce-
dure for opening the service cover may lead to
cover damage.
tbl2013-009-040_a
Step 1: Push down s ervice cover and HOLD
Step 2: Lift the front part of service cover
tbl2013-009-041_a
Step 1: Keep on lifting the front part of service cover
Step 2: Gently release the cove r post from its grommet then
release the post on the oth er side
PREDELIVERY 2014-1 19 / 34
