Cabinet Safety
16 / 48 H171764_6_001
• Select Shutdown (or Reboot) in the PDU Display.
Figure3.4: The PDU Display
Note: The PDU itself remains on even after the shutdown procedure has been completed.
The PDU must be switched off by using the mains switch described in the next section.
3.3.2 Emergency Shutoff
The mains switch powers down the console including the PDU after a controlled shutdown.
The mains switch of the AVANCE consoles also serves as an EMERGENCY OFF, for
instance if no controlled shutdown through the PDU is possible.
Figure3.5: Location of the Emergency Shutoff on the AVANCE NEO Series
