3 OVERVIEW- KSO CONSTRUCTION
WITH CLADDING
Pos. Designation Description
1 KSO Base frame with combustion chamber, top mount accumulator and front
2.1 Trim moldings construction kit round or square; in different materials
2.2 Base ring Execution depending on cladding
2.3 Footplate Execution depending on base ring
3 Mounting frame optional cover or mounting frame, shape depending on cladding
4 Flue outlet optional vertical or horizontal connection
5 Cover for flue outlet optional for vertical or horizontal flue outlet connection
© 2021 Brunner GmbH Installation Guide KSO 33 (1.12) 5
