22 T419S Indicator User Instructions
Menus
Date Set - Use the numeric keys to enter the correct date in the style chosen
below.
Style - Choose the style of date display from these choices:
l MMDD2Y
l MMDD4Y
l DDMM2Y
l DDMM4Y
Site ID Use the alphanumeric keys to enter a Site ID, up to six characters.
Seal Shows the status of the physical seal jumper inside the indicator: SEAL or
NO SEAL. If the unit is sealed, no changes can be made to the
configuration of the indicator.
Archive This item appears only if so configured in the ADMIN password protected
menu. This stands for electronic archive. In other regions it is known as an
alibi memory or tally roll. These will be transmitted via configured
communications ports. These reports can be used to confirm a weighment
if it is ever in dispute. Only records that are qualified as a LEGAL record,
per site motion criteria, are considered as entries to this log.
You can exit the menu by following the instructions in Escaping or exiting from a menu
on page 13.
4.2 About menu
If you access the About menu you will see this menu:
The date format is how the date is stored internally. Printed dates will appear as
programmed in the selected print format.
The indicator has memory capacity to store approximately 5,000 transactions.
The Archive report uses a rolling memory configuration (FIFO) so the oldest
transaction will be written over first when all the memory slots are filled.
Definitions:
Bootloader Software that makes the electronics run.
Firmware Embedded system software that creates core functions of the product.
App Specific software that controls the behaviour for a given installation.
App SerialBoot Firm Option Enet
DLoad BSQ
