T419S Indicator User Instructions 15
3.2 Accumulation weighing application
3.2.2 Net weighing
Net weighing is available via three types of tare entry.
Pushbutton tare When enabled press TARE to tare the weight on the scale.
Entered tare When enabled key in a tare weight and press TARE to set.
Preset tare When enabled press TARE and then enter a stored Preset Tare
number (1 - 10) and press ZERO to set.
Auto Tare Clear
If auto tare clear is enabled, after a weighment, when the weight falls into the gross zero
band, tare is cleared to zero.
The three types of tare are explained below.
Using Pushbutton Tare
To perform a net weighment using pushbutton tare, power up the unit and follow these
steps:
1. With no weight on the scale, if the display does not read 0 press ZERO …
0 is displayed and the center-of-zero annunciator lights.
2. Place item to be tared on the scale …
Weight is displayed.
3. Press TARE …
0 is displayed and the NET weight is displayed.
4. Place material to be weighed into or on the tared item on the scale …
Net weight of material is displayed.
5. Repeatedly press SELECT to view the gross, tare, and net values.
6. If repeated weighments use the same tared item, you do not need to establish
a new tare value as described in step 2 and 3.
Pushbutton and Entered Tares can be enabled simultaneously.
Definition: Gross zero band - this is a configured value that defines a window around
gross zero. This is used in several ways in different applications.
Pressing TARE will perform the tare function but if you continue to press and hold
TARE for 3 seconds the display will show cLEArEd and the Tare weight is cleared.
