BTL 2000 Series - 3.2 Technical parameters ADAPTER BTL-282

BTL-2000
USER'S MANUAL & USER’S GUIDE
Page 30 z 45
3.2 Technical parameters ADAPTER BTL-282
General Parameters
- Weight – equipment incl. supply cable 0,3 kg ± 10 % (0,2 kg without supply cable)
- Dimensions (l x w x h) 135 x 72 x 32 mm ±3 %
- Cover grade according to EN 60529 IP40
- Mode of operation Continual
- Indication of operation
Green LED on the right, next to the output connector
Operating Conditions
- Ambient temperature + 0 °C to + 40 °C
- Relative humidity 30 % to 75 %
- Atmospheric pressure 700 hPa to 1060 hPa
- Position Horizontal on legs
Storage and transport conditions
- Ambient temperature - 10 °C to + 55 °C
- Relative humidity 25 % to 85 %
- Atmospheric pressure 650 hPa to 1100 hPa
- Position N/A
Power supply
- Voltage AC 110V to 230V (±10% tj. ~99V to ~253V )
- Frequency 50 Hz – 60 Hz
- Input Max. 42 VA
- Class according to IEC 536 II
- Inlet type Mini 2 poles
- Fuses (IEC 60127-3/IV) Internal T500mA (can be exchanged only by the manufacturer)
Insulation barriers:
- mains – output (output cable, plastic
cover)
4 kV
Output parameters
- output voltage 13V ± 0,5V; ripple 100mVpp at consumption of 1,5ADC
- output current 1,5A ; short-time (max. 10sec) 2A
Descripton of pictograms on the equipment applied part of the type BF
equipment with double insulation
*) The stated values are maximum. The actual values depend on the type of the connected laser generator and on the purchased
configuration of the equipment.
**) Adjustable only in the pulse mode; in the continuous mode it is always 100 %.
***) The zero frequency means the continuous mode of the laser operation.
****) Frequency is standardly adjustable within the range 0 – 1000 Hz. Upgrade of the frequency range up to 5000 Hz is a part
of the above-standard accessories of the equipment.
