BTL-2000
USER'S MANUAL & USER’S GUIDE
Page 7 z 45
DIAG
A B C D E 1 2 . , : ;
PROG
F G H I J 3 4 + - * /
MAN
K L M N O 5 6 ( ) < >
MENU
P Q R S T 7 8 @ # $ &
TAB
U V W X Y Z 9 0 ! ? ´
For entering sentences (name, diagnosis, etc.) the [ + ] push button moves cursor to the right, acting as a spacebar,
and the [ - ] push button moves the cursor to the left deleting previous characters.
2.2 Instrument Assembly and Initiation
Carefully unpack instrument and place on a sturdy and level surface (max. 15° angle). Place in cool, dry environment
out of reach from direct sunlight. Instrument generates heat when in use therefore it should not be placed in the
vicinity of other heat generating devices. This may cause overheating of instrument. The instrument is cooled by
natural air convection. Do not cover instrument with flammable materials. Do not place instrument in proximity of
devices that emit strong eletric, magnetic, or electro-magnetic fields (motors, transformers, X-rays, etc.). This can
cause electromagnetic interference. In case of any misunderstanding, please contact your BTL service
representative.
Before the INITIAL turning on of instrument, check the Voltage Converter located on the adapter to insure it
is in the correct position and in accordance with the mains voltage parameters. Voltage coversion is further
described in the chapter Maintenance 2.12. In case of any misunderstanding, please contact your BTL service
representative.
We recommend proper storage of the instrument box in case additional transport of instrument is necessary.
The instrument applies irradiation only, it does not apply any pharmaceuticals or substances.
Connecting instrument (DOOR connector on the lower panel) with the door contact is recommended. For further
information see Safety 2.13.
The power will be ON following the pressing of the mains power switch on the upper panel. When the battary is low, a
“Low battery“ warning will be signalled on the display. It is then necessary to connect the mains power adapter to
recharge the battery.
When turning the instrument on you MUST NOT press any buttons on the front panel. This will generate the
error sign “Error 100 – Keyboard button jammed”. It is then necessary to turn off the instrument for minimum
of three seconds to allow it to reset. (See NOTE).
It is now necessary to enter a code to unlock the instrument. The manufacture code is preset as 0000. If it is not
modified you can continue by pressing the [ENTER] push button. It is possible to change the code using the
instructions in the chapter User diagnoses 2.4.1. Once the accurate code has been entered, the display shows th
main menu. If there are any other reactions after the turning on of the instrument do not attach laser probe and
contact BTL service technician before further use.
NOTE: After turning the instrument on and before the entering of the code, the instrument is testing its internal
functions (∼ 0.5 sec.). If the instrument finds an internal problem, you will see the error notice “Error“ and the
instrument will then be locked in Safe Mode. In this case, it is necessary to contact your BTL service representative. If
the error notification “Error 100 – Keyboard button jammed“ is displayed, it is either an operating error or it is
possible a button is jammed. In the second case, try to release the affected button or contact your BTL service
representative.
2.3 Starting Operation
Switch the instrument on by pressing the power switch on the upper panel. Enter the safety code on initial screen.
BTL-2000
T HER APEUTIC LASER
E N T E R CODE: 0000
