Installation and Connections
SM-DIN/MULTILOOP.. - 2.7 -
MSC DEVICES IDENTIFICATION
(Only for service/optional devices)
MSC IDENTIFY
Enter the BOARD SETUP menu
Select IDENTIFY.
Select MSC IDENTIFY.
/
To increase/decrease the value
3 sec
to confirm and go to next parameter
To move from one parameter to the other
/
To increase/decrease the value. This parameter corresponds to the
number to be assigned to the first sensor/device to be identified. (if
sensor not present select OFF)
3 sec
To start the device identification
3 sec to confirm and go back to BOARD SETUP menu
BOARD SETUP
→
IDENTIFY
