btsr SM-DIN/MULTILOOP/ETH - Page 44

Installation and Connections
SM-DIN/MULTILOOP.. - 2.24 -
/
To change the parameter value [1 … 1000 cN]
3 sec to confirm and go back to WRK PARAMETERS menu
PFD STRETCH RANGE
Enter the WRK PARAMETERS menu.
Select PFD PARAMETERS
/
To change the parameter value for each single position
Control of stretch regulation range of Prefeeder. Default value is 100 corresponding
to a range ±10%.
/
To change the parameter value [10…..90%]
3 sec to confirm and go back to WRK PARAMETERS menu
WRK PARAMETERS
→
PFD PARAMETERS
→
PFD STRETCH RANGE
