Installation and Connections
SM-DIN/MULTILOOP.. - 2.26 -
TMS/TS55 SENSOR OFFSET
(The following example refers to a configuration with TMS sensors)
Enter the TMS OFFSET menu.
To enter the parameter change.
To change the range of sensors for which the offset shall be
executed (*)
3 sec to confirm the offset procedure on the selected sensors
At the end of the offset procedure the main menu will be displayed
(*) Prior to execute the offset, remove the yarn from the loading cell of the selected sensors
DIAPER FEEDER DEVICE OFFSET
Enter the DF OFFSET menu.
To enter the parameter change.
To change the range of devices for which the offset shall be
executed (*)
3 sec to confirm the offset procedure on the selected devices
At the end of the offset procedure the main menu will be displayed
(*) Prior to execute the offset, remove the yarn from the loading cell of the selected devices
