6. Connecting to a Net Base
6. Connecting to a Net Base
Connect the pigtail to the AC/DC wall adapter.
Connect the AC/DC wall adapter to the Net Base.
Plug the AC/DC wall adapter into an AC power outlet.
Open the enclosure lid.
Move the toggle switch down to the ON position.
X80 Wireless Camera User's Manual v2.0 12 of 35
Net Base
1
Net Base
2
Net Base
3
The AC/DC wall adapter is for indoor use only.
Net Base
4
O
N
Net Base
5
