Instrument Range
To meet the needs of different industrial users, a selection of DCCT instruments has been created in the
Pro2 range.
•
All instruments are installed in a robust powder-coated aluminium housing.
•
They are mains (90 – 250V AC) powered and can output from 900V to 40kV.
•
The alarm threshold range is from 10 to 450µA.
•
All units are fitted with an interlock loop facility and an internal alarm sounder, coupled with an
alarm triggered DPDT relay which allows interconnection with PLC or other parts of the
installation.
•
User-settable software controls enable selection from a range of responses to alarms to suit the
installation requirements.
•
All instruments are capable of networking, allowing up to four output units to be connected to a
single command station.
DCCT Pro2 Integral – Single Output
(6002-0098)
This is the basic instrument which replaces the previous generation of DCCT. It provides a digital user
interface, and a single channel output assembly. In addition to offering a greater, and more stable,
output over the whole range, visual alerts are provided on-screen, the backlight will be blue if HV is
energised, and red if a fault is detected, along with an audible alarm. Faults are counted on a
resettable digital counter, and a remote button connection is provided for HV on-off control. The
instrument is installed in a rack-mountable (19” 2U) case and provided with rack mounting accessories.
DCCT Pro2 Integral – Dual Output
(6002-0099)
This is identical to the above, but as the name suggests, it provides two DCCT output channels which
are controlled in parallel from the same digital user interface. It provides identical features as the
previous instrument, and likewise, is installed in a rack-mountable (19” 2U) case and provided with rack
mounting accessories.
DCCT Pro2 Command +
(6002-0100)
This instrument provides the same command, control and reporting capabilities as the preceding
instruments, but does not include an output assembly. The instrument is mounted in a smaller case and
provides a means of remotely operating other instruments. As above, visual alerts are provided on-
screen, the backlight will be blue if HV is energised, and red if a fault is detected, along with an audible
alarm. Faults are counted on a resettable digital counter, and the relay outputs are also provided in
this instrument. The Command + unit is connected to other units via a 4-core network cable, which
may be up to 100m long.
DCCT Pro2 Single Channel Output Unit
(6002-0101)
This comprises a mains-powered output unit, mounted in a 19” 2U powder-coated housing. The
specifications & capabilities are identical to the single channel Integral unit, but there is no command
interface within the instrument – it must be networked with one of the preceding instruments.
DCCT Pro2 Dual Channel Output Unit
(6002-0102
)
This is identical, however as with the Dual Output Integral unit, the instrument contains two output
channels.
