Buckleys DCCT PRO2 - EC Declaration of Conformity; UKCA Declaration of Conformity; Specifications

Instruction Manual
4 06/23
EC Declaration of Conformity
We, Buckleys (UVRAL) Ltd., as sole manufacturer of the apparatus listed below, declare that the
product
DCCT Pro2 is manufactured in conformity with the following directives: 2014/30/EU , 2014/35/EU ,
2015/863/EU and 2011/65/EU (RoHS) .
Date: 01/06/2023
Authorised by:
J P Hoveman
CEO, Buckleys (UVRAL) Ltd.
UKCA Declaration of Conformity
We, Buckleys (UVRAL) Ltd., as sole manufacturer of the apparatus listed below, declare that the
product
DCCT Pro2 is manufactured in conformity with the following UK legislation: Electronic
Compatibility Regulations 2016
, The Electrical Equipment (Safety) Regulations 2016 and Restriction of the
Use of Certain Hazardous Substances in Electrical and Electronic Equipment Regulations 2012
.
Date: 01/06/2023
Authorised by:
J P Hoveman
CEO, Buckleys (UVRAL) Ltd.
Specifications
Note: Due to ongoing technical developments, all stated information is typical and is subject to change
without notice or obligation.
• Mains Supply Voltage: 90-250VAC
(via IEC C13 “Kettle Plug” lead)
• Output voltage range: 0.9kV – 40kV
• Max. output current: <1mA (continuous)
• Alarm sensitivity range: 10μA to 450μA
(factory-set to 200μA)
• Unit: 3.8kg, 420mm x 240mm x 90 mm
• Packed weight: 4.1kg
• Dimensions (packed): 580mm x 420mm x
220mm
• Meter accuracy: <10kV: +/- 10V. >=10kV +/-
100V
• Current meter FSD: 450μA
• Maximum relative humidity: 80% non-
condensing
• Temperature range: 0ºC - +40ºC
Output voltage range:
Model Low Range Increment High Range Increment
DCCT Pro2 0.9kV-10kV 10V 10.1kV-40kV 100V
