Buddipole PowerMini USB User Manual

Specification
POWERmini USB User Guide 15 2.0
SPECIFICATIONS
Battery Type
Lithium ion or Lead Acid
Maximum Battery Input Voltage
1
24 V DC
Minimum Battery Input Voltage
10V DC
Maximum Solar Input Voltage
24 V DC
Minimum Solar Input Voltage
N/A
Maximum Load Current (total)
35 A (continuous)
Maximum Solar Charge Current
11 A
Number of 12V DC output ports
2
DC power connectors
Anderson Powerpole® 45A
USB charger output connector
USB type A connector
USB charger output voltage
5V
USB charge maximum output current
1.5A
Reverse Polarity Protection
Battery and Solar Panel inputs
Over voltage disconnect range
14 – 16 V (user adjustable)
Low voltage disconnect range
10.5 – 13 V (user adjustable)
Maximum Charge Voltage
12-15 V (user adjustable)
Audible alarm
User settable enable, disable
Overall Size
4.5 (W) x 3.2 (D) x 1.3 (H) inches
115 (W) x 82 (D) x 33 (H) mm
Weight
6.2 oz (176g).
Operating Temperature Range
0 – 40 degrees Celsius
1
The maximum battery input voltage is the maximum that the POWERmini will accept. The voltage will
not be applied to the radio unless it is below the High Voltage Limit set in the user settings.

Buddipole PowerMini USB Specifications

Battery

battery type	Lithium ion or Lead Acid
maximum battery input voltage	24 V DC
minimum battery input voltage	10V DC
maximum solar input voltage	24 V DC
maximum solar charge current	11 A
maximum charge voltage	12-15 V (user adjustable)

Power

maximum load current	35 A (continuous)
over voltage disconnect range	14 – 16 V (user adjustable)
low voltage disconnect range	10.5 – 13 V (user adjustable)

Ports & Interfaces

number of 12V DC output ports	2
DC power connectors	Anderson Powerpole® 45A
USB charger output connector	USB type A connector

Operating Environment

operating temperature range	0 – 40 degrees Celsius
reverse polarity protection	Battery and Solar Panel inputs
audible alarm	User settable enable, disable

Weight and Dimensions

overall size	4.5 (W) x 3.2 (D) x 1.3 (H) inches
size in mm	115 (W) x 82 (D) x 33 (H) mm
weight	6.2 oz (176g)
