Special functions (additional menu) 9
65
We reserve the right to make any changes due to technical modifications.
Operating instructions RC30 programmable room thermostat • Issue 02/2006
You can enter a value in the range from –5.0 to +5.0 (factory
setting 0.0). The "K" in the display stands for the unit Kelvin; 1 K
corresponds to 1 °C.
Example: If the temperature displayed by the thermometer is
0.5 °C higher than that displayed by the RC30, enter "+0.5 K" as
the calibration value.
Release the "Display" button. The set calibration value is stored.
Press the "Back" button or close the flap.
CALIBRATION
ACT ROOM TEM
+0.5 K
USER NOTE
You can also have an additional room temperature sensor
installed for the RC30. This is useful if you want to measure the
temperature in another room with the RC30, for example if the
comparison with a thermometer is still unsatisfactory even after
calibration.
