23
External dimensions
(excluding protruding parts)
39 x 189 x 123 mm
Power consumption 18 W (Max)
Power AC 100 - 240 V 50/60 Hz
Compatible OS
Windows 8 (32-bit and 64-bit)
Windows 7 (32-bit and 64-bit)
Windows Vista (32-bit and 64-bit)
Windows XP (32-bit)
OS X 10.5 or later (models with Intel Processor)
*1 Connect the DriveStation to a USB 2.0 port for best transfer speeds. The DriveStation will function when connected to
a USB 1.1 port, but data transfers will be slower.
WARNING:
This product and its components contain chemicals known to the State of California to cause cancer and birth defects,
or reproductive harm. Wash hands after handling.
HD-LXU3
Diagrams
1
2
3
4
1
Power / Access / Lock LED
Normal mode Encrypted mode
Idle
Normal Blue/Green -
Locked - Red
Authenticated - Blue/Green
Active Blinking (Blue/Green)
Power O O
Blue for USB 3.0
Green for USB 2.0 or 1.1
2
USB Connector
