SECTION 3: OEM Pyrometer Locations (vehicle w/DPF only)
PYROMETER LOCATION AND OVERVIEW:
The diagrams below shows where Pyro 1 and Pyro 2 are installed on the 2007.5 and newer light
duty diesel trucks. There is no installation required for these pyrometers; each pyrometer is OEM.
The temperatures at each location are displayed on the GT as a vehicle parameter under the
gauge setup menu.
FORD POWER STROKE
