54
Turn your Brinco upside down and
place the seat and handlebars on a
flat surface. Place a wooden block
or similar under the handlebar grips
to prevent the display from touching
the ground. You should also place a
cloth on the seat so that it does not
get stainned or damaged.
Unplug the motor connector (1)
which is anchored in the swing arm
support. It will be as easy as slightly
rotating it a quarter turn.
[Check 3.2.1 to see how to unplug
the connector].
Unscrew the bolt (2) that holds the
engine cable on the swing arm with
a T25 Torx wrench.
REAR WHEEL DISASSEMBLING
WE RECOMMEND CARRYING OUT
THIS WORK WITH THE BRINCO
BATTERY DISCONNECTED
ALL THE IMAGES IN THIS SECTION SHOW YOUR BRINCO IN AN INVERTED POSITION (UPSIDE DOWN).
BEFORE ANY OPERATION,
ENSURE YOUR BRINCO IS
TURNED OFF
A B C
