Machine Composition
Exterior Overview
Product Outlets and Removable Parts
A. User Interface
B. Display
C. Hot Water Outlet
D. High Lime Sprayhead
E. Dilution Nozzle
F. Funnel Sensing Coil
G. Data Plate
H. Rail Locator
I. Top Cover Vents
J. Optional Hot Water Outlet
K. Bypass Outlet
L. Ventilation Hole
On/off switch (on the right panel)
User Interface
The user interface is a membrane switch adhered to the front of the brewer. The membrane is connected to the
control board by a ribbon cable. The user interface allows the user to select the product, batch size and to begin
the brew cycle.
The machine’s display is mounted to the control board. The display is visible on the front of the machine and
provides information to the user and to the technician.
