Bunn ITB Technical Training

Bunn-O-Matic Corporation
9
Rail Locators
The rail locators are factory set to accommodate Thermal Fresh servers and TDO-N dispensers. The rails can be
inverted to t with regular tea dispensers by detaching the screws on the bottom of the brewer that secure the rails.
ITCB HV Interior Overview
Internal Components
TF Servers and TDO-N Dispensers
Regular Tea Dispensers
*Thermistor
CBA
Solenoid for Bypass System
Solenoid
(Dispense Valve)
120 VAC Fan
Thermistor
*Transformer
(Relocated)
Dual Inlet
Solenoid
Dillution Hose
