Control
US1
Highest set-value setting
Set-value limits 1 for operator
US2
Highest set-value setting
Set-value limits 2 for operator
S1C
Control function 1
in = inverted (Heating, humidifying)
dir = direct (cooling, dehumidifying)
S2C
Control function 2
in = inverted (heating, humidifying)
dir = direct (cooling, dehumidifying)
AC
Minimum switch-off period
0 ... 250 sec relay switch-off period
ouc
Dependency of the
diP = dependent (SET2 = SET1 + SET2)
set-values
ind = independent
on
Minimum switch-on period
0...250 sec relay switch-on period
ono
Minimum delay
0...120 min; minimum delay between two
activations of the control relay.
Alarms
ALC
Configuration
rE = relative to the set-value (in Kelvin)
Temperature alarm
Ab = absolute values (in °C)
ALL
Low temperature alarm
If SET - ALL undershot, a low tempe-
rature alarm will be triggered after the
delay time ALd.
ALU
Over-temperature alarm
If SET + ALU exceeded, a high tempe-
rature alarm will be triggered after delay
time ALd.
ALH
Hysteresis for the
Automatic alarm acknowledgement:
Limit value alarms
For high alarm, undershooting of
ALL and ALU
ALU - ALH and low alarm for exceeding
ALL + ALH
ALd
Alarm delay
Minimum time in which the conditions for
at
temperature over/
Alarm situation must be present.
Undershoot
(0...999 min)
dAO
Alarm delay at for
Suppression of alarms after
mains ON (0...23.5 h)
Commissioning
So1
Status of the control relay
oFF = opened
with sensor fault
on = closed
So2
S Status of the control relay
oFF = opened
with sensor fault
on = closed
