Alarms
tbA Status of the control relay oFF = Relay deactivated
after acknowledgement on = Relay activated
(any button) in any
alarms ituation
AS Configuration of the alarm cL = Terminal 5-6 closed
relay at an alarm oP = Terminal 5-6 closed
Measured value display
LCI Lower analog Lower display value at current input
Display value 4 mA or at voltage input 0 V
(-1999...1999) (only for the inputs 0-20 mA, 0-1V,
0-10 V)
UCI Upper analog Upper display value at current input
display value 20 mA or at voltage input 1 V or 10 V
(-1999...1999) (only for the inputs 0-20 mA, 0-1V,
0-10 V)
rES Resolution Selecting display resolution
in = integer (-99...+199)
dEC = 1 decimal point (-99.0...199.0)
cE = 2 digits after the decimal point
(-99.00...199.00)
1,2
irE = large measuring range
(-999...1999)
1,2
UdM Units Display of the units directly in the
illuminated display. Regardless of which
controller type is being used:
see General description
PbC Type of sensor Type of inout
Temperature sensor U): J = Thermoelement „J“; Pt = Pt100;
C = Thermoelement „K“; Ptc = PTC;
S = Thermoelement „S“; ntc = NTC
Current / voltage input cur = 4...20 mA; 0-1 = 0...1 V;
(AU) 10 = 0...10 V
1
Only for devices with an input of 4...20 mA or 0...1 V or 0...10 V
2
Only for current or voltage input
ATTENTION!
If rES is changed at a later time, the following parameters must
be checked::
SET, Hy1, LS1, uS1, ALL, ALu, ALH, LCi, uCi, LAo, uAo, HES
NOTE Selecting a decimal point is not possible for thermocouples.
