Conversion of control function
Type 2000, 2002, 2012
9.5 Conversion from ow below the seat to ow above
the seat
DANGER!
Danger – high pressure!
▶ Turnothepressureandventthelinesbeforelooseninglinesorvalves.
Risk of injury from improper maintenance!
▶ Maintenance may be performed by authorized technicians only!
▶ Toscrewonorunscrewvalvebodyoractuator,useanopen-endwrench,neverapipewrench.
▶ Observetighteningtorques.
Item Description
28,29 2PressurespringsforactuatorC,D,E,F
→ Mount valve
1
on the body.
CAUTION!
Danger through taut springs!
▶ Carefully open piston actuator!
→ Release cover
31
withspecialwrenchuntilthespringsarecompletelyrelaxed,holdinguptheactuator
body
12
againstthehexagon.
Forinformationaboutthespecialwrench,seeChapter“10Installationtools”.
→ Removeand/orinsertpressuresprings
28 29
dependingonactuator.
→ ForactuatorsizeC,D,EandF:Removepressurespringsandinsertnew,weakersprings.
→ ForactuatorsizeG,H:Removeouterspringonly
29
innerspring
28
remains in the actuator.
→ Mount cover
31
andscrewtightlywithspecialwrench.
→ Check the valve for function and leaks.
Notechangeddirectionofowandchangedpressurerange!
