8
Technical data
Silicone
PC
PC
PPO
Silicone
Stainless steel 304
Stainless steel 316 (A4)
PBT, contacts in gold-plated
copper alloy
Figure 2 : Materials used for the multiCELL
112
10111
102
112
55
107
max. 4 mm
(wall thickness)
Figure 3 : Dimensions of the multiCELL [mm]
6.3.2. Specifications of the "M0:MAIN" board
Power supply 12-36 V DC, filtered and regulated
Specifications of the power source (not
provided) of UL-recognised devices, with
variable key PE72
• Limited power source (in accordance with chap. 9.3 of the UL
61010-1 standard)
• or class 2 type power source (according to the 1310/1585 and
60950-1 standards)
Type 8619
english
