Technical data
Max. power consumption (without additional
module, outputs not connected)
1.5VA
Power distribution ("PWR OUT") 12-36 V DC, 1.8A max.
All digital inputs ("DI") • Switching threshold V
on
: 5 à 36 V DC
• Switching threshold V
off
: < 2 V DC
• Input impedance: 3kW
• Galvanically insulated
• Protected against polarity reversal and voltage spikes
• Frequency: 0.5 to 2500Hz
All analogue outputs ("AO") • 4-20mA current
• Any connection mode, in sink or source mode
• Galvanically insulated
• Protected against polarity reversal
• Max. loop impedance: 1100W at 36V DC, 610W at 24V DC,
100W at 12V DC
All digital outputs ("DO") • Transistor
• Connection mode unimportant in NPN or PNP mode
• Galvanically insulated
• Protected against short circuits
• Max. voltage: 36V DC
• max. 700mA if one transistor is connected but max. 1A for both
transistors connected
• Max. frequency: 2000Hz
Electrical connection
• Per detachable 21-point set-screw connector, orange
• Refer to chap. 6.3.8 for the specifications of the connection
cables
Flow rate measurement (software option) Refer to the user manual for the flow sensor connected to the 8619
6.3.3. Specifications of the input board "Input"
Power consumption 0.1 VA
Digital inputs ("DI") • Switching threshold V
on
: 5 à 36 V DC
• Switching threshold V
off
: < 2 V DC
• Input impedance: 3 kW
• Galvanically insulated
• Protected against polarity reversal and voltage spikes
• Frequency: 0.5 to 2500 Hz
Type 8619
