12
Technical data
Conductivity measurement (with
connected conductivity sensor)
• Measurement range
• Measurement resolution
• Measurement error
• 0.000 µS/cm...2 S/cm (depends on the conductivity sensor)
• 10
-9
S/cm
• < 0.5% of measured value + sensor error
Resistivity measurement (with connected
conductivity sensor)
• Measurement range
• Measurement resolution
• Measurement error (without sensor)
• 0.500W.cm...100MW.cm (depends on the conductivity sensor)
• 10
-1
W.cm
• < 0.5% of measured value
Temperature measurement
• Measurement range
• Measurement resolution
• Measurement error
• Temperature sensor type
• -40°C ... 200°C
• 0.1°C
• ±1°C
• Pt100 or Pt1000, with 2 or 3 wires
Electrical connection
• Per detachable 9-point set-screw connector, green
• Refer to chap. 6.3.8 for the specifications of the connection
cables
6.3.8. Specifications of the connection cables
• Use shielded cables for the electrical connection.
• Be sure to use cables in which the wires present the specifications described in the table below.
Wire specifications Dimensions of the max. clamping area
• Single core H05(07) V-U 0.2...1.5 mm
2
• Flexible wire H05(07) V-K 0.2...1.5 mm
2
• With non-insulated end connection 0.2...1.5 mm
2
• With insulated end connection 0.2...0.75 mm
2
Table 1: Specifications of the wires making up the connection cables
Type 8619
english
