Burnham FREEDOM - Page 32

32
5) SnorkelTerminalInstallation-TheSnorkelKit(P/N101544-01)consistsofthefollowing(AlsoseeFigure7.34):
Key No. Part No. Description
1 101620-01 Support Elbow
2 101621-01 Lower Wall Bracket
3 101622-01 Air Intake Section
4 101623-01 Wall Bracket
5 101624-01 Terminal Elbow
6 101625-01 Exhaust Terminal
7 101490-01 Standard Elbow
8 101626-01 Wall Penetration Section
* 101627-01 Outer Joint Gasket (2 provided)
a)Cuta6”diameterholethroughtheexteriorwallattheplannedexitpointofthevent.Aminimumof4”isneeded
betweenthecenterlineofthisholeandgradetoinstallthelowerwallbracket.
b)Beforemountingthelowerwallbracket,loosentheM10x35screwonthisbracket.Adjustthisboltforwardor
backwardsothatitscenteris6-7/16”fromthewall(Figure7.34)andtighten.
c)CentertheLowerWallBracketontheholeinthewallandmarkthelocationofthefourmountingscrewsonthewall.
5/16”mountingscrews(notsupplied)arerecommendedformountingthisbracket.Drillmountingholesandmount
thebracket.
IMPORTANT
The Terminal Elbow and Wall
Penetration Section included in
the snorkel kit have gaskets in the
female end of the outer pipe. These
gaskets prevent in ltration of rain
water into the air intake section.
Do not interchange with similar
components shown in Table 7.4b.
Figure 7.34: Installation of Snorkel Terminal
