NOTICE
Ingress of foreign objects or liquids.
Risk of damage to the machine!
If the inlet gas contains dust or other foreign solid particles:
• Install a suitable filter (5micron or less) upstream from the machine.
Connection size(s):
– Ø 114 mm for WT 0100 CV/CP and WT 0150 CV/CP
– Ø 159 mm for WT 0280 CV/CP and WT 0390 CV/CP
– Ø 219 mm for WT 0600 CV/CP and WT 0730 CV/CP
Depending on the specific order, other connection dimensions may apply.
5.4.2 Discharge Connection
Connection size(s):
– Ø 114 mm for WT 0100 CV/CP and WT 0150 CV/CP
– Ø 159 mm for WT 0280 CV/CP and WT 0390 CV/CP
– Ø 219 mm for WT 0600 CV/CP and WT 0730 CV/CP
Depending on the specific order, other connection dimensions may apply.
• Make sure that the discharged gas will flow without obstruction.
5.5 Filling Oil
NOTICE
Use of an inappropriate oil.
Risk of premature failure!
Loss of efficiency!
• Only use an oil type which has previously been approved and recommended by
Busch.
For oil type and oil capacity see Technical Data [►31] and Oil [►33].
When the oil filling is achieved:
• Write down the oil change date on the sticker.
Last oil change
__ / __ / ____
Oil type see nameplate
Change interval see
instruction manual
If there is no sticker (part no. 0565 568 959) on the machine:
• Order it from your Busch representative.
