12 Technical Data
WT 0100 CP/CV WT 0150 CP/CV WT 0280 CP/CV
Inlet flow
(50Hz)
m³/min 2.5 – 10.0 3.7 – 15.0 5.1 – 28.0
Nominal motor rating
(50Hz)
kW 1.5 – 22.0 3.0 – 37.0 3.0 - 55.0
Max. differential pressure
Pressure operation
hPa (mbar) 1000 1000 1000
Max. differencial pressure
Vacuum operation
hPa (mbar) 500 500 500
Nominal motor speed
(50Hz)
min
-1
1150 - 4700 1150 - 4700 850 – 4100
Ambient temperature range °C -15 … 45
Max. gas inlet temperature °C 60
Relative humidity at 30°C 90%
Weight pump stage approx. kg 75 92 167
Weight unit without cabinet kg 180 197 346
Weight unit with cabinet kg 295 312 535
WT 0390 CP/CV WT 0600 CP/CV WT 0730 CP/CV
Inlet flow
(50Hz)
m³/min 7.1 – 39.0 12.0 – 64.0 15.4 – 73.0
Nominal motor rating
(50Hz)
kW 3.0 - 55.0 11.0 – 90.0 11.0 – 90.0
Max. differential pressure
Pressure operation
hPa (mbar) 1000 1000 1000
Max. differencial pressure
Vacuum operation
hPa (mbar) 500 500 500
Nominal motor speed
(50Hz)
min
-1
850 - 4100 750 - 3500 750 – 3500
Ambient temperature range °C -15 … 45
Max. gas inlet temperature °C 60
Relative humidity at 30°C 90%
Weight pump stage approx. kg 193 336 375
Weight unit without cabinet kg 372 711 750
Weight unit with cabinet kg 561 1014 1053
