Transport | 3
0870231979_WT0100-0730CP_CV_-0001_IM_en 7 / 36
3 Transport
WARNING
Suspended load.
Risk of severe injury!
• Do not walk, stand or work under suspended loads.
WARNING
Lifting the machine using the motor eye bolt.
Risk of severe injury!
• Do not lift the machine using the eye bolt fitted to the motor. Only lift the machine as
shown.
NOTICE
In case the machine is already filled with oil.
Tilting a machine that is already filled with oil can cause large quantities of oil to in-
gress into the casing.
• Drain the oil prior to every transport or always horizontally transport the machine.
• Check the machine for transport damage.
If the machine is secured to a base plate:
• Remove the machine from the base plate.
