7 | Maintenance
22 / 36 0870231979_WT0100-0730CP_CV_-0001_IM_en
Drain pan
Cleaning cloth
Oil draining at the gear side
For oil type and oil capacity see Technical Data [►31] and Oil [►33].
When the oil filling is achieved:
• Write down the oil change date on the sticker.
Last oil change
__ / __ / ____
Oil type see nameplate
Change interval see
instruction manual
If there is no sticker (part no. 0565 568 959) on the machine:
• Order it from your Busch representative.
