BWB XP - Sample Area and Chimney Components

Sample area & chimney
12
Flame Inspection
Port
Outer Chimney
Mixing Chamber
Retaining Clips
Mixing Chamber
Nebuliser Retaining
Screw & Bracket
Nebuliser
Drain Cup fitted
with Level Sensor
U-tube
Drip Tray
Sample
Cup
Aspiration
Tube
Gas Flow Adjuster &
Guard
NOTE: adjustment is
made by turning the
metal knob, not the
black guard.
