K Calibration- ppm
Number of
Points (0): 1
Annex D
LCD screen detailed breakdown
Calibration screens
Element and
Unit of
Measure
Previous amount of
calibration points
calibrated for this
element. If no previous
calibration exists (new
install or deleted
config) this will display
(0).
New amount of
calibration points for
this element, entered
using the numerical
keypad.
K Calibration- Pt 1
accept Preset or
Enter Concentration
(50.0ppm):
Displays the calibration
point currently being
configured
As above. This shows the
element was last
calibrated at 50.00ppm,
pressing Accept will use
this value. Alternatively,
enter a new value using
the numerical keypad.
K Calib- Pt 1
asp 60.5ppm
Flushing Chamber . . .
--- - 12
Element and
calibration
point
An indication of
the calibration
standard to be
aspirated.
Li 1 Point R2=1.000
Blank: 385 Raw
01: 10.0 ppm
1720 Raw
View calibration
Element and amount of
calibration points
Indication of the R2 value
for the calibration.
The RAW value for the
Blank
The calibration point,
toggle using the Keypad
‘Up’/ ‘Down’ arrows on
keys 6 & 9.
The concentration, units of
measure and RAW for the
calibration point indicated
at the top of the screen.
Indication of
automated process
Stability
indication
line
Time
elapsed
To Next Page
