Start Up
Before attempting to start up the instrument make sure all the Installation instructions have been followed and the safety statements have
been understood.
Initial checklist:
Ensure the mains lead is connected and the supply is switched
on.
Check the gas hose is connected and has been leak tested.
Open the cylinder valve.
If an Alternate Air source is being used, ensure the rear panel
AIR switch is set to the EXT position and the external air source
is connected to the rear panel air nozzle. Switch on the external
air supply.
Check the Drain Cup is filled to overflowing and the waste tube
has a free flow.
Switch on the instrument using the rear panel power switch.
1>Turn on Flame
2 Maintenance
3 Setup
XP
Flame Photometer
F4.00X32 H4.00 02.13
A flash screen displays the instrument model type and firmware.
Once the system has undergone self diagnostics the welcome
screen is displayed.
The gas adjustment valve will be in an approximate optimised
setting, either from initial BWB factory testing or from your
previous period of testing. Adjustment can be made during
ignition if required. Please note that the black plastic guard is not
the handle, do not turn the black guard, turn only the small silver
knob.
Press Accept or 1
The ignition sequence will start, a spark should be noticed through
the chimney inspection flap.
If required, increase the gas flow using the valve to aid ignition.
Please note that if adjusting the valve, it does not have an ‘end
stop’; it is possible to remove the needle from the valve and
cause gas leakage into the room. Ensure the instructions for
opening the valve are adhered to.
With successful ignition, the Main menu will be displayed:
1>Read
2 AutoRead
3 Calibrations
4 Setup
At this point in the Start Up procedure, open the Flame
Inspection Port and make sure the flame has ignited. If not, turn
off the power immediately! Allow the unit 30 seconds for
capacitors to discharge and then re-attempt lighting the flame. If
multiple attempts are unsuccessful, refer to Troubleshooting or
contact your local agent.
17
