BWT COVERDECK - 9. Control Panel Assembly - Finishing; Final Control Panel Assembly and Wiring

4
6
3
Use the bracket as a template for drilling.
Attach the bracket to the wall using the bushing
and screws provided.
Hang the control panel on the panel and replace
the holding screw.
5
Put the cable gland in position, tighten the holding
screws. Make the connections and tighten the
cable holding nut.
Replace the front panel once wiring is complete.
