BWT COVERDECK - 16.2 Separating Wall and Sub-Coping Plate Assembly; Dimensions for Separating Wall Installations

BWT COVERDECK
Print Icon
To Next Page IconTo Next Page
To Next Page IconTo Next Page
To Previous Page IconTo Previous Page
To Previous Page IconTo Previous Page
Loading...
200
3,5
49
3,5
Cornière
Fixation des chevilles à 25mm
par rapport à l'arase du bassin
20 cm béton mini
19
96
Ø 54 max
35 mini.
86,5 15
75 25
85
22 mm mini.
15 max.
40183
12
95
20
52.6
20 cm concrete min
Water level with
respect to the top
of the pool
Coping
M30
135 mm
Coping
M40
125 mm
Coping
M55
110 mm
19
96
Ø 54 max
35 mini.
86,5 15
75 25
85
22 mm mini.
15 max.
40183
12
95
20
52.6
19
96
Ø 54 max
35 mini.
86,5 15
75 25
85
22 mm mini.
15 max.
40183
12
95
20
52.6
Coping minimum overhang 22 mm
maximum overhang 35 mm
16.2 With seperating wall and coverdeck SUB-coping mounting plate
Recess to pass
cables
Sub-coping
mounting plate
Coverdeck beam
housing
Concrete reserve
zone height
20 cm
Coverdeck motor
Coverdeck beam
95 cm duckboarding
HungResurfacing
Pool
level
Detail, top of the wall
Water level
Sub-coping
mounting plate
Coverdeck
end fixing
plate
**PLEASE NOTE THAT DIMENSIONS ARE QUOTED IN CM, UNLESS OTHERWISE INDICATED**
VERY IMPORTANT
2019/01 - Indice de révision : N - Code : 34201 PROTECTION & SÉCURITÉ
54/60
