BWT COVERDECK - 16.3 Separating Wall and Stardeck Cement-Bedded Units; Dimensions for Stardeck Cement-Bedded Installations

Water level with
respect to the top
of the pool
Coping
M30
135 mm
Coping
M40
125 mm
Coping
M55
110 mm
96
Ø 54 max
40
75
25
18
3
35 mini.
85
15 maxi
52.6
200
3,5
49
3,5
Cornière
Fixation des chevilles à 25mm
par rapport à l'arase du bassin
20 cm béton mini
Ø 54 max.
3
84
40
18
19,6
15 max
10 max
12
50
20
35 mini.
52.6
96
Ø 54 max
40
75
25
18
3
35 mini.
85
15 maxi
52.6
16.3 With seperating wall and STARDECK cement-bedded units
Stardeck
beam
housing
Coverdeck end
fixing plate
Recess to pass
cables
Stardeck beam
housing
Concrete reserve
zone height
20 cm
Coverdeck motor Stardeck beam
95 cm Duckboarding
Water level
HungResurfacing
Pool
level
Detail, top of the wall
**PLEASE NOTE THAT DIMENSIONS ARE QUOTED IN CM**
VERY IMPORTANT
20 cm concrete min
