BWT COVERDECK - 16.5 Pit Wall and Sub-Coping Mounting Plate Assembly; Dimensions for Pit Wall & Sub-Coping Plate Setup

7
73
12.5
60
20
35 mini.
3
40
63
6
Ø 54 max.
15 max.
10 max.
13
52.6
69
Water level with
respect to the top
of the pool
Coping
M30
135 mm
Coping
M40
125 mm
Coping
M55
110 mm
200
3,5
49
3,5
Cornière
Fixation des chevilles à 25mm
par rapport à l'arase du bassin
20 cm béton mini
16.5 With pit wall and coverdeck sub-coping mounting plates
Cut a 10 mm recess beneath the coping to house
the flange
Recess to pass
cables
Coverdeck
mounting unit
Concrete reserve
zone height
20 cm
Coverdeck motor
Stardeck beam
68 cm Duckboarding
Sharp angle (90°) conguration
Water level
HungResurfacing
Pool
level
Detail, top of the wall
**PLEASE NOTE THAT DIMENSIONS ARE QUOTED IN CM**
VERY IMPORTANT
2019/01 - Indice de révision : N - Code : 34201PROTECTION & SÉCURITÉ
57/60
