152 5-2 Air Conditioning System
5-2 Air Cond itioning System
A/C control panel
With the vehicle powered up (OK), the air conditioning system can be used.
■ Configuration 1
1 Compressor control button
2 A/C ON/OFF button
3 Front windshield defrosting button
■ Configuration 2
1 Blower speed decrease button (press
this button once to decrease the blower
speed by one level)
2 Blower speed increase button (press
this button once to increase the blower
speed by one level)
3 A/C compressor cooling button
4 Air distribution mode button
(press this button to switch among air to
face, air to footwell, air to face +
footwell, air to footwell + defrosting)
5 Internal/external air recirculation on/off button
6 A/C ON/OFF button
Temperature regulation knob (turn the knob toward the red direction to increase
the set value of A/C temperature; turn the knob toward the blue direction to
decrease the set value of A/C temperature)
7 A/C display interface
