BYD EPS14P - Travel, Steering, and Braking; Low Speed Control; Fork Lifting and Lowering

OPERATING
OPERATOR MANUAL
24
EPS14P
25
OM-EPS14P2019001-EN
2. Steering
When travelling, turn the tiller right or left to steer.
3. Braking
Rotate the tiller to the areas of A1 and A3 to brake; Release the accelerator button B to brake;
when the vehicle speed is 0, apply the brake immediately.
A1
A2
A3
B
Low Speed Control
Press the low speed control below the tiller, and then the vehicle goes into low speed mode.
Fork Lifting and Lowering
Press the lift control button to lift the fork.
Press the lower control button to lower the fork.
