BEFORE MAINTENANCE
Before Maintenance
Before maintenance, place the vehicle on the sturdy and level ground, let the tiller on the
initial position, turn off the vehicle, press the emergency switch button and block the vehicle.
Emergency Lowering
If the fork can't be lowered by a fault of the vehicle loosen the pressure relief switch to lower
the fork.
After lowering the fork, tighte
n the pressure relief switch.
Move the Vehicle with the Electric Fault
When the electric failure occurs, the electromagnetic brake stops the vehicle. Loosen screws
and remove the brake, and then move the vehicle.
Caution
(1) Tow the vehicle by rigid connection only.
(2) Tow the vehicle at low speed.
