BYD EPS14P - Horn and Emergency Switch; Display (A type); Display (B type)

OPERATING
OPERATOR MANUAL
26
EPS14P
27
OM-EPS14P2019001-EN
Horn
Press the horn button to send audible warning.
Emergency Reversal Switch
When the emergency reverse switch is striked, the vehicle will travel forward for some
distance until it's not striked.
DISPLAY USING
Display (A type)
There is a screen and an indicator in the display. The screen shows the battery level, repairing
sign, low speed sign, hour meter and fault code. The indicator light indicates low battery level or
repairing.
4
1
2
3
5
6
No. Name Descriptions
1 Warning Indicator The indicator twinkles when the vehicle breaks down or the battery level is low.
2 Repairing Sign The repairing sign appears when the vehicle breaks down.
3 Low Speed Sign The low speed sign appears after the low speed control being pressed.
4 Hour Meter Sign The hour meter sign appears after the vehicle being normally started.
5 Hours and Fault Code
The time worked appear
s after the vehicle being normally started. The fault code
appears when the vehicle breaks down.
6 Battery state
The battery level is shown by ten notches, and each notch represent the 10% of
the battery charge. The number of notches displayed by the battery varies with the
actual battery level
Display (B type)
There is a screen and a light ring in the display (B type). The screen shows the battery lev
el, hour
meter and fault code. When a certain controller of the vehicle has fault, the light ring displays red,
and the interface displays the current fault code.
No. Name Descriptions
1 Warning Indication
When the battery is low or the vehicle
has fault, the light ring displays red,
and the interface displays the current
fault code.
2 Speed Display
It displays the current speed when the
vehicle being normally started.
3 Working Hour Display
The time worked appears after the
vehicle being normally started.
4 Battery state Battery level is shown as a percentage




