5 Internet Basic Configuration
ZTE ONU series of products support route function, Internet can work by route
mode or bridge mode, the difference between the two modes are as follows:
Routing mode Broadband Internet access: ONU as a home gateway
equipment, ONU on route mode can obtained IP address in three ways: DHCP,
static IP and PPPoE. The IP address of the user terminal device (PC, etc.)
obtained by the ONU own DHCP address pool or manually set the static IP
address the same as DHCP address pool.
Bridging mode broadband Internet access: ONU itself will not get the IP
address assigned by the upper device, or can not manually set the static IP address,
then ONU as a relay device. The IP address of the user device (PC) connecting the
ONU LAN port obtained by the OLT upper layer server. The PC is connected to the
Internet through DHCP, PPPoE, and static ip address.
5.1 Routing mode broadband Internet settings
5.1.1 PPPoE broadband Internet access in routing mode
1. web login ONU and select Network -> WAN -> WAN Connection, and then
set the following parameters:
【Connection name】Select "Create WAN Connection".
【New Connection name】According to own convenience to specify.
【Enable Vlan】This one can be set according to the network planning situation, if
the network planning Internet vlan, this one need to check the
"Enable vlan"; If the network is not planning Internet vlan, this one
does not need to check, then ONU is vlan transparent mode.
【 Vlan ID】 The same as "Enable Vlan", Setting depending on the network vlan
planning.
【802.1p】Set the priority of vlan, The same as "enable Vlan", depending on the
network vlan planning to configure. The default priority is 0.
【Type】select "Route".
【 Service List 】 Select internet. route mode access internet are generally select
