QT601-2 Quantec Controller
Installation & Programming Manual • Approved Document No. DNU6012001 Rev 5 • Page 27 of 42
Appendix 2 - The Datalogging Function
Log Record Format
The first line states the time that the log output was started. After that the records are extracted from the log, oldest first, and are
downloaded to the output device in the following form: (a) date; (b) hour / minute; (c) location description; (d) type/level of call;
(e) low battery signals (from infrared neck pendants and infrared staff attack transmitters).
E
xample of Records as Printed:
L
og output on 1.10.02 at 11.05am
30/09 4:36pm Dining Room 1 2 3 4 Call
30/09 4:39pm Ward W A 2 3 Call
30/09 4:40pm Dining Room 1 2 3 4 Presence
30/09 4:40pm Toilet G F 1 4 Call
30/09 4:41pm Dining Room 1 2 3 4 Reset
30/09 4:42pm Ward W A 2 3 Call
30/09 4:42pm Toilet G F 1 4 Presence
30/09 4:43pm Ward W A 2 3 Assist
30/09 4:44pm Toilet G F 1 4 Reset
30/09 4:45pm Ward W A 2 3 Presence
30/09 4:46pm Ward W A 2 3 Reset
1/10 9:02am Lounge 2 Attack
1/10 9:02am Lounge 2 Reset
1/10 10:15am Bedroom G F 4 Call
1/10 10:15am Bedroom G F 4 Emergency
1/10 10:18am Bedroom G F 4 Presence
1/10 10:18am Bedroom G F 4 Reset
Fault Messages are Presented as Follows:
16/06 11:13pm Log full!
2/10 1.02pm Display 1 F 2 Device 14 Faulty
23/04 3:30am Mains supply failure!
23/04 6:23am Mains supply restored
When the Output Log function is selected (refer to section 4.2), the contents of the datalogger are transmitted to the output
device. When each record has been sent it is deleted from the datalogger and its place taken by a new event. When all the records
have been deleted the datalogger is empty and the output session is completed.
Failure to output the log: If the printer is not able to accept the data, or Automatic Output is disabled and there has been no
Manual start command, the datalogger's memory will fill to capacity. When this occurs a warning message will appear on the
Controller’s Display and a record of the warning message will be entered onto the log in the last empty record. New events after
this time are lost. This function continues until the log is output normally.
