This product has been manufactured in conformance with the requirements of all applicable EU
Council Directives.
QT601-2 Quantec Controller
Installation & Programming Manual • Approved Document No. DNU6012001 Rev 5 • Page 3 of 42
• Installation & Programming Manual (i.e. this manual).
Explains how to install, commission and maintain the
Quantec control panel.
This manual must not be left accessible to General and
A
uthorised Users.
• Manager’s / Matron’s Guide (Doc. No. DNU6012005).
Gives operational information for Authorised Users about
entering day/night mode, changing the date & time,
printing the log report, editing User IDs, etc.
• Electrical accessory pack (SAF0601001) containing the
following:
1 x Allen key for unfastening / securing the panel lid
1 x Mains fuse (1A HRC ceramic, 20 mm)
1 x set of battery connection leads.
IMPORTANT NOTES
This equipment must only be installed and
maintained by a suitably skilled and technically
competent person.
• This equipment is a piece of Class 1 equipment and MUST
BE EARTHED.
• No responsibility can be accepted by the manufacturer, or
distributors of this equipment for any misinterpretation of an
instruction, or guidance note, or for the compliance of the
system as a whole.
• The manufacturer's policy is one of continuous improvement
and we reserve the right to make changes to product
specifications at our discretion and without prior notice.
E&OE.
• When Quantec is powered up for the first time, the
Controller may need to reset its Configuration Data to default
values. The message ‘Fit NVM Link’, or ‘E’ to Abort’ will be
displayed. When the NVM link is fitted the message
‘INITIALISING DATA, PLEASE WAIT’ will flash on the display.
This procedure may take up to 1 minute and MUST be
completed before Quantec will operate properly.
S
ystem Design
Addressable Call System design is beyond the scope of this
document. A basic understanding of addressable call system
components and their use is assumed.
We strongly recommend that a suitably qualified and
competent person is consulted in connection with the design
of the call system and that the system is commissioned and
serviced in accordance with the contract specification and
national standards. The building manager responsible for the
p
roperty should be contacted at an early stage in case he/she
has any special requirements.
Equipment Guarantee
This equipment is not guaranteed unless the complete
system is installed and commissioned in accordance with the
laid down national standards by an approved and competent
person, or organisation.
ITEMS SUPPLIED WITH THE PANEL
