CAB A4 User Manual

15cab Produkttechnik GmbH & Co KG
Control / Test
Stop of print : Ribbon out
Paper / fanfold paper out
Printhead open
Test options : System test when powering on including a printhead test
short status, status print, font list, device list,
printhead profile, label profile, test grid, ASCII dump mode
Status messages : Counter of the printed length, counter of the operating hours
Others
Dimensions : A3, A4 : H: 10.8 in (274mm) W: 9.5 in (242mm) D: 17.6 in (446mm)
A6 : H: 10.8 in (274mm) W: 11.9 in (302mm) D: 17.6 in (446mm)
Weight : A3, A4 : 22 lb. (10 kg)
A6 : 31 lb. (14 kg)
Operating Voltage : 100-240 V A.C. / 50-60 Hz
Maximum Power Input : A3 : 250 W
A4, A6 : 500 W
Environment :
Operation : at 50° to 95° F (10 to 35°C) at a humidity of 30 to 85%
Transport : at -13° to 158° F (-25 to +70°C) at a max. humidity of 95%
non-condensing
Storage : at 41° to 104° F (5 to 40 °C) at a humidity of 5 to 85%
Options
External Media Unwinder/Rewinder
For operating large print jobs, external unwinders and rewinders are available
to handle big label rolls :
A3 A4 A6
External Rewinder ER1 (up to 8.3in (210mm) diameter) x x -
External Rewinder ER2 (up to 8.3in (210mm) diameter) - - x
External Rewinder ER4 (up to 11.8in (300mm) diameter) x x -
External Rewinder ER6 (up to 11.8in (300mm) diameter) - - x
External Unwinder EU4 (up to 11.8in (300mm) diameter) x x -
External Unwinder EU6 (up to 11.8in (300mm) diameter) - - x
1. Product Description

CAB A4 Specifications

General

Printer Type	Thermal transfer / direct thermal
Interfaces	USB, Ethernet, RS232
Label Thickness Range	0.05 mm - 0.25 mm
Memory	8 MB Flash
Power Supply	100-240 VAC, 50/60 Hz
Operating Temperature	+5°C to +40°C
Print Resolution	203 dpi
Humidity Range	10-85% non-condensing
