CAB A4 User Manual

32 cab Produkttechnik GmbH & Co KG
1
Switch on the Printer
Fig. 5c Switch on the printer
After making all connections, power on the printer using the power switch (1).
The printer will perform a short system test, then display "ONLINE" on the front
panel LCD.
If a hardware failure occurs during the system test, the symbol and a
description of the failure will be displayed on the LCD. In this case the printer
should be powered off and on again. If the failure re-occurs, call for service.
5. Connecting the Printer

CAB A4 Specifications

General

Printer Type	Thermal transfer / direct thermal
Interfaces	USB, Ethernet, RS232
Label Thickness Range	0.05 mm - 0.25 mm
Memory	8 MB Flash
Power Supply	100-240 VAC, 50/60 Hz
Operating Temperature	+5°C to +40°C
Print Resolution	203 dpi
Humidity Range	10-85% non-condensing
