64 cab Produkttechnik GmbH & Co KG
Print Parameters
1. Switch from "Online" mode to the Offline Menu by pressing the key.
2. Select the "Setup" menu.
3. Select the "Print parameters" menu.
Time Powersave
If the printer does not receive a print job or the front panel has not been
accessed for a period of time, the printer will switch into a powersave mode.
During powersave mode, certain functions such as the background lighting of
the display are powered off until the next operation is carried out.
This parameter defines the amount of time the printer will wait before entering
powersave mode after the last operation.
Debug mode
The "Debug mode" is a tool for the firmware programmer.
It will assist in recognizing faults and their possible sources beyond standard
error messages.
Table 8d Overview of the "Print parameters" Menu
8. Printer Configuration
Parameter Meaning
Heat level Basic adjustment of the heat
intensity
Default : 0
Print speed Basic adjustment of the print
speed
Default : 100 mm/s
Transfer print Basic selection of thermal
transfer mode / direct thermal
mode
Default : On
Setup
Print Parameters
Selection
-20 ... +10
A3/200 : 50-200 mm/s
A3/300 : 50-150 mm/s
A4/300 : 50-250 mm/s
A4/600 : 50-100 mm/s
A6/300 : 50-200 mm/s
steps of 25mm/s
On
Off
